12000 BTU 17 SEER2 208-230V Ductless Mini Split Air Conditioner and Heater

4.84
91 Reviews
Item No: 82365714
$519.00$740.0029% Off
Only $441.15 if you join Costway Plus+Details
Save extra 8% on this itemUse code: DELIGHT8See More
Delivers in 2 - 5 days
Ships To: 92337 - Fontana

This item is in transit.

Notify me when it’s back.

Log in for 519 PTS per Purchase.

Free Shipping on All Orders8-Year Warranty30-day No Hassle Return

Looking for AC Installation Services Looking for AC Installation Services?

Costway Mini Split AC Recommend

Costway Mini Split AC Recommend
Buy the best air conditioner for your home size!
See More

Product Overview

  • Remote Control IncludedRemote Control Included
  • Environmentally Friendly RefrigerantEnvironmentally Friendly Refrigerant
  • Energy SavingEnergy Saving
  • 8-year Warranty8-year Warranty
  • Automatic Cleaning of Gold FinsAutomatic Cleaning of Gold Fins
  • Precharged Condenser and Heat PumpPrecharged Condenser and Heat Pump
  • Installation Required: Licensed HVAC InstallerInstallation Required: Licensed HVAC Installer
  • Low NoiseLow Noise
  • AHRI CertificationAHRI Certification

Specifications

Color: White
Material: Iron, Aluminum, Plastic
Indoor Unit Size: 31" x 8" x 11.5"(L x W x H)
Outdoor Unit Size: 29" x 11" x 21"(L x W x H)
Cooling Capacity: 12000 BTU
Heating Capacity: 12000 BTU
Cooling Power:  1180W
Heating Power: 1080W
Coverage Area:  750 sq. ft.
Air Flow Rate:  1354 CFM
Voltage:  AC 208-230V~60Hz/1PH
Dehumidifying Capacity: 36 Pints/Day
Temperature Setting Range: 60℉~90℉
Refrigeration: R32
Timer:  0.5-24 Hours
Indoor Noise Level:  41 dB
Outdoor Noise Level: 54 dB
Net Weight of Indoor Unit: 22 lbs
Net Weight of Outdoor Unit: 55 lbs
HSPF2: 8.5
SEER2: 17
EER2:  10

Exchange & Redeem in the shopping cart!

4pcs 18 x 18 Inches Square Throw Pillows

4pcs 18 x 18 Inches Square Throw Pillows

These 18 x 18 inches square throw pillows are perfect for adding comfort and style to your living space!

  • Overview

  • Reviews

  • Q&A

  • Manuals

Overview

-8 years Warranty for compressor and 5 years for parts to ease your worries.
-Shipped in 2 boxes and may be delivered at different times
-Fast cooling and heating with a wide coverage area of 750 sq. ft.
-4-in-1 design and built-in 1-ton heat pump offer all-year-around comfort for you
-60°F-90°F adjustable temperature and 4 fan speeds for customized comfort
-High-efficiency gold fins ensure good heat transfer performance and long-lasting use
-Multiple modes include dry, excellent, heat, fan, auto, sleep, ECO, turbo, iFEEL, etc
-Washable filter and self-clean function let you enjoy fresh and clean air
-Innovative inverter technology improves the energy efficiency ratio
-Auto up-down and left-right swing promote air circulation
-The 26ft remote control and LED display for easy operation
-0.5-24H timer and quiet operation for a peaceful and comfy sleep
-Auto defrost function prevents damage to the outdoor unit
-ETL and AHRI certification ensures safe and long-lasting use
-The item comes in 2 boxes and delivery time may be different per box, please contact us if you have any questions.
-The installation of this equipment should be done only by a Licensed HVAC Installer.
-Package Includes an Outdoor Unit, an Indoor Unit, an 8ft Power Line, a 13ft Copper Connection Pipe - Air Pipe, a 13ft Copper Connection Pipe - Liquid Pipe, a 6.5ft Drain Hose, a 15ft Communication Wires, a Remote Control, a Tape, a Putty, a Wall Sleeve, and a User Guide

Installation guide

Where to Install a Costway Ductless Mini Split Air Conditioner

How to Install a Costway Ductless Mini Split Air Conditioner

Compare Similar Items

  • 12000BTU 17 SEER2 208-230V Ductless Mini Split Air Conditioner and Heater

    12000BTU 17 SEER2 208-230V Ductless Mini Split Air Conditioner and Heater

    $519.00$740.00

  • 9000 BTU 17 SEER2 208-230V Ductless Mini Split Air Conditioner and Heater

    9000 BTU 17 SEER2 208-230V Ductless Mini Split Air Conditioner and Heater

    $499.00$623.00

  • 18000 BTU 19 SEER2 208-230V Ductless Mini Split Air Conditioner and Heater

    18000 BTU 19 SEER2 208-230V Ductless Mini Split Air Conditioner and Heater

    $729.00$911.00

  • 23000 BTU 18.5 SEER2 208-230V Ductless Mini Split Air Conditioner and Heater

    23000 BTU 18.5 SEER2 208-230V Ductless Mini Split Air Conditioner and Heater

    $1029.00$1286.00

Indoor Air Handler Size
31" x 8" x 11.5"
31.2" x 8" x 11.5"
37" x 8.5" x 12"
44" x 9"x 13"
Outdoor Condenser Size
29" x 11" x 21"
28" x 11"x 21"
31.5" x 12" x 21.5"
32" x 12" x 25.5"
Cooling Capacity
12000 BTU
9000 BTU
18000 BTU
23000 BTU
Heating Capacity
12000 BTU
9000 BTU
18000 BTU
24000 BTU
Voltage
208-230V
208-230V
208-230V
208-230V
Coverage Area
750 sq. ft.
450 sq. ft.
1250 sq. ft.
1500 sq. ft.
SEER2
17
17
19
18.5
HSPF2
8.5
8.5
9
8.3
Sound Rating, Indoor
41 dB
42 dB
47 dB
50 dB
Sound Rating, Outdoor
54 dB
53 dB
54 dB
58 dB
Dehumidifying Capacity
36 Pints/Day
38 Pints/Day
67.5 Pints/Day
115 Pints/Day
24 Hour Timer
Yes
Yes
Yes
Yes
AHRI Certification
Yes
Yes
Yes
Yes
APP Control
x
x
x
x
Refrigeration
R32
R32
R32
R32

Reviews

4.84
91 Reviews
5
90.1%
82
4
6.6%
6
3
1.1%
1
2
2.2%
2
1
0%
0

Frequent Mentions

  • K

    Cools nicely

    Affordable and works great. My handyman installed and said it was simple to install great so far!

    costway-img
    Preview
  • A

    So So Good

    My husband and I moved into a new home and realized the hvac didn’t work . It would have costed over $5000 to get repaired . Thank God we saw this. Been over a year now and the heating and cooling on this is still great . It lasted up through freezing temperatures and the heatwave . May purchase another one too

    costway-img
    Preview
  • J

    Great Purchase

    Unit working great. Installed in bonus room and had no issues. Had to extend lines 20’ and didn’t have to add any freon. Quick shipping and will buy again. Thinking of putting one in my garage.

    costway-img
    Preview
  • A

    Air Conditioner 12000 BTU

    This was a great purchase. My garage gets up to 90 degrees in the summer. with this unit its much cooler. very pleased with the purchase.

    costway-img
    Preview
  • J

    I Am Very Please With This Mini Split System

    I purchased this mini split to go in my mother's first floor of her townhouse. I calculated the amount of square footage we would be cooling and looked up online which size of air conditioner would be recommended for her situation. The recommended size was 12,000 BTUs. I ordered the 110v model (instead of the 220v) as that voltage is easier to work with and would work out to be slightly more efficient on the electric bill each month. This was the first mini split I ever installed. I was able to watch a few videos online showing installation of mini splits and the process was very clear. I took my time and installed the entire thing in about 7 hours. The only additional parts I needed was screws to mount the inside unit to the wall, a bracket for the outdoor unit to sit on (see pics), a power disconnect box for outside (as required by national code), power wire to run from the disconnect box over to the house circuit breaker panel, a line set cover for the lines running to the outdoor unit, and a new circuit breaker so the unit could be on it's own circuit breaker. All of these additional parts cost me around $130. I followed the included instructions on how to install it (after watching the videos online). I feel that anyone who can do automotive repair competently and has general experience working with home electrics can install this with ease. When we first powered the system on, we were pleasantly surprised at how quickly it began to cool and how remarkably quiet both inside and outside units are. It's crazy how well it works compared to a window air conditioner and yet it costs very little more. The unit has been installed and running for a week now and I am very please with the purchase. My mother has no problem understanding how to operate it and the unit draws very little power so I do not expect a substantial change to her electric bill.

    costway-img
    Preview
    costway-img
    Preview
    costway-img
    Preview

Q&A

  • Q:
    Can you install this yourself?
    A:
    It requires professional personnel to install it.
    Costway representative
  • Q:
    What does LF on the units front readout mean?
    A:
    Please forward your question or concern as well as the order number to our customer support at [email protected]. After order confirmation, our customer support are standing by and ready to help you resolve any issues you may have.
    Costway representative
  • Q:
    With the recent temperature drop outside my new 12000 btu 230V mini split outdoor unit frosted up. I had to put it in cooling to defrost it. Any thoughts as to why?
    A:
    Please forward your question or concern as well as the order number to our customer support at [email protected]. After order confirmation, our customer support are standing by and ready to help you resolve any issues you may have.
    Costway representative
  • Q:
    does the remote have a thermostat and does the Ifeel function allow you to set a temperature and the unit turn on and off by itself
    A:
    Press the ifeel button, and the air conditioner will sense the temperature of the room. Change the temperature from the air inlet of the air conditioner to the temperature around the remote control. The remote control is usually placed in an area where people are active, which is closer to the temperature perceived by the human body, making temperature control more precise and comfortable for the human body. In automatic mode, the temperature display on the remote control will disappear and default to 24 ℃. The constant temperature will continue to work and cannot be changed.
    Costway representative
  • Q:
    How do you find the sku number to register the warranty
    A:
    There is no need for you to register the warranty of the item,Mini split air conditioner is protected with 8 years warranty for the compressor and 5 years for parts.
    Costway representative
  • Q:
    Is a vacuum pump needed for installation?
    A:
    Yes, it needs to be vacuumed.
    Costway representative
  • Q:
    How long is the lineset and how can i order with different lengths
    A:
    13ft. We do not have different lengths line sets for sale.
    Costway representative
  • Q:
    What size area can one of ur units heat and cool
    A:
    17-23 square meters.
    Costway representative
  • Q:
    Is the mini split system UL certified?
    A:
    Yes, it is listed in UL.
    Costway representative
  • Q:
    We have purchased a 12,000 BTU, 208-230V Ductless Mini Split. What would my conductor size be that supplies power to my unit? Max fuse is 10A, but LRA is 25. Per the installation manual page 16 for 10 amps I should run 18awg. We both know this is wrong. 25 Amps it shows I should run 12awg. Romex or THHN, there is a difference in max ampacity with these two options of conductor. Looking forward to your feedback.
    A:
    Please forward your question or concern as well as the order number to our customer support at [email protected]. After order confirmation, our customer support are standing by and ready to help you resolve any issues you may have.
    Costway representative
